| X5 Portable High Resolution Music Player from FiiO Features & Specifications |
September 14, 2014 Introduction • Closer Look • X5 Buttons & Scroll Wheel • X5 Menu |
Features & Specifications • Conclusion General Specifications Model X5 Firmware Installed 2.0 Color Available Black Dimensions 67.6mm x 114mm x 15.6mm Weight 195g Display Screen IPS 400x360 (260K colors) Analog Audio Output Jack 3.5mm headphone output jack Digital Audio Output Jack 3.5mm headphone output jack USB DAC Supports 192KHz/24Bit Phone out (PO) 3.5mm headphone output jack Headphone Impedance Range 16~300Ω Volume Control Type 0-120 level digital volume control Bass Boost 10-band graphic EQ Treble 10-band graphic EQ Left / Right Channel Adjustment 5 dB Gain Selection OFF ("L"): 0 dB ON ("H"): 6 dB Partial Performance Parameters For Line Output THD+N < 0.0025%@1KHz |
Frequency Response 20Hz~20KHz(+/-0.1) Crosstalk > 100 dB @10KΩ @1KHz SNR > 115dB (A-Weight) Dynamic Range > 115dB Line Output Level > 1.5 Vrms Partial Performance Parameters For Phone Out Output Power 1 > 460 mW@16Ω THD<1% Output Power 2 > 255 mW@32Ω Output Power 3 > 28 mW@300Ω Frequency Response 20Hz~20KHz(+/-0.1) SNR > 115 dB (A-Weight) Output Impedance <0.26Ω Crosstalk >75 dB@1KHz THD+N < 0.003%@1KHz MAX Output Voltage > 8 Vp-p MAX Output Current > 150 mA Power And Battery Power USB 5V/500mA USB 5V 2A (recommended) Charge Display Red light indicates charging Green light indicates fully charged Battery Display Yes Type Of Battery Lithium Polymer Battery Voltage 3.7V Battery Capacity 3700 mAH Battery Life ~10hrs (firmware 1.0) 12-15hrs (firmware 2.0) Charging Time < 4 Hours Audio Formats Supported DSD DSD64 (2.8MHz/1bit) DSDIFF (.dff) DSF (.dsf) HE-AAC Supported as of Firmware 2.0+ APE Up to 192KHz/24Bit for Fast Compression Up to 192KHz/24Bit for Normal and High Level compression Extra High and Insane compression NOT supported FLAC Up to 192KHz/24Bit for compression levels from 1-8 ALAC (Apple) Supports 192KHz/24Bit AAC (Apple) Supported WAV Up to 192KHz/24Bit WMA Up to 96KHz/24Bit OGG Supported MP3 Supported MP2 Supported What's In The Package
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
