DSLR Imager Sizes, Pixel Sizes, and FOV Equivalency Factors
(Last Updated: July 13, 2008)

Below is a compilation of as many DSLR cameras as I could possibly find. It's a great resource if you ever wonder how large a particular imager/sensor is. The following table is also meant to be used with The FOVEF table.



Camera.... Imager Size (W x H) FOV Factor Pixel Size MPt MPe
All 35mm 36.0mm x 24.0mm None or 1.0x -- -- --
Canon D30 22.7mm x 15.1mm 1.6x 10.27m x 10.27m 3.25MP 3.11MP
Canon D60 22.7mm x 15.1mm 1.6x 7.4m x 7.4m 6.52MP 6.30MP
Canon 300D/Digital Rebel 22.7mm x 15.1mm 1.6x 7.4m x 7.4m 6.52MP 6.30MP
Canon 10D 22.7mm x 15.1mm 1.6x 7.4m x 7.4m 6.52MP 6.30MP
Canon 20D 22.5mm x 15.0mm 1.6x 6.4m x 6.4m 8.25MP 8.20MP
Canon 20Da 22.5mm x 15.0mm 1.6x 6.4m x 6.4m 8.25MP 8.20MP
Canon 30D 22.5mm x 15.0mm 1.6x 6.4m x 6.4m 8.25MP 8.20MP
Canon 40D 22.2mm x 14.8mm 1.6x 5.59m x 5.59m 10.50MP 10.10MP
Canon 1D 28.7mm x 19.1mm 1.3x 11.5m x 11.5m 4.48MP 4.15MP
Canon 1D Mark II 28.7mm x 19.1mm 1.3x 8.2m x 8.2m 8.5MP 8.2MP
Canon 1D Mark II n 28.7mm x 19.1mm 1.3x 8.2m x 8.2m 8.5MP 8.2MP
Canon 1D Mark III 28.7mm x 19.1mm 1.3x 7.16m x 7.16m 10.7MP 10.1MP
Canon 1Ds 35.8mm x 23.8mm 1.0x 8.8m x 8.8m 11.4MP 11.1MP
Canon 1Ds Mark II 35.8mm x 23.8mm 1.0x 7.09m x 7.09m 17.2MP 16.7MP
Canon 1Ds Mark III 36.0mm x 24.0mm 1.0x 6.28m x 6.28m 21.90MP 21.10MP
Canon 5D 35.8mm x 23.9mm 1.0x 8.02m x 8.02m* 13.30MP 12.80MP
Fuji S2 Pro 23.0mm x 15.5mm 1.5x 7.41m3 6.49MP 6.17MP
Fuji S3 Pro 23.0mm x 15.5mm 1.5x 7.83m x 7.83m3 6.45MP2 6.17MP2
Kodak DCS Pro 14n 36.0mm x 24.0mm 1.0x 7.9m x 7.9m 13.89MP1 13.50MP1
Kodak DCS Pro SLR/n/c 36.0mm x 24.0mm 1.0x 7.9m x 7.9m 13.89MP 13.50MP
Konica-Minolta Maxxum 7D 23.7mm x 15.7mm 1.5x 7.68m x 7.68m 6.31MP 6.10MP
Leica Digital-Module-R 26.4mm x 17.6mm 1.37x 6.8m x 6.8m ??? 10.01MP
Nikon D40x 23.6mm x 15.8mm 1.5x 5.89m x 5.89m 10.75MP 10.20MP
Nikon D50 23.7mm x 15.6mm 1.5x 7.8m x 7.8m 6.24MP 6.10MP
Nikon D60 23.6mm x 15.8mm 1.5x 5.89m x 5.89m 10.75MP 10.20MP
Nikon D70 23.7mm x 15.6mm 1.5x 7.8m x 7.8m 6.24MP 6.10MP
Nikon D70s 23.6mm x 15.8mm 1.5x 7.8m x 7.8m 6.24MP 6.10MP
Nikon D80 23.7mm x 15.6mm 1.5x 5.57m x 5.57m 12.0MP 10.2MP
Nikon D100 23.7mm x 15.6mm 1.5x 7.8m x 7.8m 6.31MP 6.10MP
Nikon D1 23.6mm x 15.5mm 1.5x 11.8m x 11.8m 2.70MP 2.66MP
Nikon D1X 23.7mm x 15.6mm 1.5x 5.93m x 11.89m 5.47MP 5.33MP
Nikon D1H 23.7mm x 15.6mm 1.5x 11.89m x 11.89m 2.74MP 2.66MP
Nikon D200 23.6mm x 15.8mm 1.5x 5.81m x 5.81m 10.92MP 10.20MP
Nikon D2H 23.7mm x 15.5mm 1.5x 9.4m x 9.4m 4.26MP 4.10MP
Nikon D2Hs 23.7mm x 15.5mm 1.5x 9.4m x 9.4m 4.26MP 4.10MP
Nikon D2X 23.7mm x 15.7mm 1.5x 5.52m x 5.52m* 12.84MP 12.40MP
Nikon D2Xs 23.7mm x 15.7mm 1.5x 5.52m x 5.52m* 12.84MP 12.40MP
Nikon D300 23.6mm x 15.8mm 1.5x 5.34m x 5.34m 13.10MP 12.30MP
Nikon D700 36.0mm x 23.9mm 1.0x 8.17m x 8.17m 12.87MP 12.10MP
Nikon D3 36.0mm x 24.0mm 1.0x 8.19m x 8.19m 12.87MP 12.10MP
Olympus E-1 17.3mm x 13.0mm 2.0x 6.8m x 6.8m 5.5MP 5.0MP
Olympus E-3 17.3mm x 13.0mm 2.0x 4.37m x 4.37m 11.8MP 10.1MP
Olympus E-300 17.3mm x 13.0mm 2.0x 5.4m x 5.4m 8.9MP 8.3MP
Olympus E-330 17.3mm x 13.0mm 2.0x 5.32m x 5.32m 7.94MP 7.50MP
Olympus E-500 17.3mm x 13.0mm 2.0x 5.4m x 5.4m 8.9MP 8.3MP
Olympus E-510 17.3mm x 13.0mm 2.0x 4.54m x 4.54m 10.9MP 10.0MP
Pentax *ist D 23.5mm x 15.7mm 1.5x 7.65m x 7.65m 6.31MP 6.10MP
Pentax *ist DS 23.5mm x 15.7mm 1.5x 7.65m x 7.65m 6.31MP 6.10MP
Pentax *ist DL 23.5mm x 15.7mm 1.5x 7.65m x 7.65m 6.31MP 6.10MP
Pentax *ist DS 23.5mm x 15.7mm 1.5x 7.65m x 7.65m 6.31MP 6.10MP
Sigma SD9 20.7mm x 13.8mm 1.7x 9.12m x 9.12m 3.54MP 3.43MP
Sigma SD10 20.7mm x 13.8mm 1.7x 9.12m x 9.12m 3.54MP 3.43MP
Sigma SD14 20.7mm x 13.8mm 1.7x 7.70m x 7.70m 4.82MP 4.69MP


MPt = Total Megapixels on imager.
MPe = Effective Megapixels on imager. Effective means the number of pixels that are actually used in the image you are viewing. We are also seeing "Recorded Pixels" in the latest user manuals and on camera manufacturer websites, which mean the same thing. However, do take note this could change. Since Fuji has used the term "effective pixel" to mean photodiode (and Foveon is doing something similar), we may have to use Recorded Pixels (or "Active Pixels") to even be more specific.

* = Estimated Pixel Size.

1Kodak says 13.85MP online but also says 13.7MP in their DCS Pro 14n manual. Nothing major to worry about, and this is more of an FYI.

2Fuji gives their new 4th-generation Super CCD SR sensor the specs of 6.45 million S-pixels /6.45 million R-pixels total pixels; 6.17 million S-pixels /6.17 million R-pixels effective pixels to deliver 12.9 million total pixels, 12.34 million effective pixels. If that's not confusing, I don't what is. Bottom line, it's a 6.45 tMP / 6.17 eMP sensor.

3After several emails to Fuji, I still haven't received a response to their pixel sizes. Maybe someday I will. Until then, I did my own calculations for the Fuji S2, since it doesn't have the terribly confusing and nebulous descriptions of two different pixels.
