Fujitsu ScanSnap S500
(Windows/PC Version)
Specifications
June 21, 2006
Introduction Installing The ScanSnap S500 ScanSnap Manager v4.0 (Part 1)
ScanSnap Manager v4.0 (Part 2) ScanSnap Manager v4.0 (Part 3) ScanSnap Organizer v3.0
Cardminder v3.0 ABBYY FineReader For ScanSnap 2.0 / PDF Transformer 1.0
Specifications Conclusion Additional Images



ScanSnap S500
MSRP $495.00
Scanner Type ADF (Automatic Document Feeder), Duplex color scanning
Output Color/B&W/Automatic color and B&W detection
Image Sensor Color CCD x 2
Optical Resolution 600 dpi
Scanning Speed (A4) Normal mode Color 150dpi, B&W 300dpi :
18 pages per minute / 36 images per minute
Better mode Color 200dpi, B&W 400dpi :
12 pages per minute / 24 images per minute
Best mode Color 300dpi, B&sW 600dpi :
6 pages per minute / 12 images per minute
Excellent mode Color 600dpi, B&W 1,200dpi :
0.6 pages per minute / 1.2 images per minute
Scanning Range A4, A5, A6, B5, B6, Business card, Letter, Legal and Custom sizes (can set for up to 5 different paper types) / Automatically recognizes paper type by paper length
Use of Carrier sheet permits the scanning of A3, B4, double letter and photographs as well as those listed above.
Paper Weight (thickness) 52 to 127g/m (14 to 34 lb)
Hopper Capacity 50 Sheets (20lb)
Interface USB 2.0 (USB 1.1 Compatible)
Driver ScanSnap Specific Driver
(TWAIN/ISIS® not supported)
TWAIN or ISIS applications cannot be used directly
Applications Adobe Acrobat 7.0 Standard, ABBYY FineReader for ScanSnap 2.0, CardMinder™ v3.0, ScanSnap Organizer v3.0
Compatible Operating System WIN 98SE/2000/XP
Power Requirement AC 100 to 240V, 50 / 60 Hz
Power Consumption Scan mode: 28W or less,
Sleep mode: less than 6W
Operation Environment Temperature 5C to 35C (42F to 95F)
Relative humidity 20 to 80% (non-condensing)
Dimensions (W x D x H) 284 x 157 x 158 (11.2 x 6.2 x 6.2 in.)
Device Weight 5.9lbs. or less, without power adapter
Environmental Compliance ENERGY STAR® Compliant
Limited Warranty 1 year Limited Warranty. For full details, visit the warranties page or call (800) 626-4686.
Service Options In-Warranty Upgrade - Advance Exchange Post-Warranty - Advance Exchange Plus For full details on all service programs, visit www.ImagingService.com
Part Number PA03360-B505
