Sigma Product Announcement: APO 100-300mm F/4.0 EX DG HSM

September 9, 2005

Fast aperture telephoto zoom lens that provides excellent optical performance for Digital SLR cameras and film SLR cameras.

This telephoto zoom lens provides a large F4 aperture at all focal lengths. The new multi layer lens coating and lens design reduce flare and ghosting, and also maintains minimal light-fall-off, superior peripheral brightness is ensured.

Reduces flare and ghosting

New multi layer coating of this lens gives superb color performance whilst cutting down flare and ghosting caused by reflections from the digital image sensor. High optical performance is demonstrated throughout the entire zoom range. Employs SLD (Super Low Dispersion) Glass

Two SLD glass elements are used in the front lens group and two in the rear lens group for superior correction of several aberrations for superior image quality throughout the entire zoom range.

Silent high-speed AF with HSM

The Hyper Sonic Motor (HSM) ensures a silent, high-speed AF function as well as full-time manual focusing capability for Sigma, Canon, and Nikon-D mount lenses.

Inner focusing and inner zooming systems

An inner focusing system eliminates front lens rotation, making the lens particularly suitable for using the petal-type lens hood supplied and circular polarizing filters. Since focusing and zooming do not change its overall length, ease of handling and operation is assured. A rotating tripod mount can be conveniently detached if required.

APO Tele-Converter EX (optional)

High-speed focusing is possible when this lens is used with dedicated APO EX tele-converters (1.4x and 2x). With the optional APO tele-converter 1.4x EX, it works as AF zoom lens from 140mm to 420mm F5.6. With APO tele-converter 2.0x EX, it works as a manual focus zoom lens from 200mm to 600mm F8.




Sigma APO 100-300mm F/4.0 EX DG HSM
Focal Length 100-300mm
Minimum Aperture F32
Lens Construction 16 Elements in 14 Groups
Angle of View 24.4 - 8.2 degrees
Number of Diaphragm Blades 9
Minimum Focusing Distance 180cm (70.87)
Maximum Magnification 1:5
Filter Size 82mm
Lens Hood Bayonet Type Hood
Dimensions Diameter 92.4mm (3.64)
Length 226.5mm (8.92)
Weight 1480g / 52.21oz
